Advanced SMT THT DIP SMT PCB Assembly with HDI PCB Board and Min. Solder Mask Bridge 0.075mm

Product Description:

The HDI PCB Board is a high-quality product designed for various electronic applications that require advanced technology and precision engineering. With a thickness of 1.6mm, ±10%, this board offers a sturdy and reliable base for your electronic projects.

Featuring the latest in high density interconnector technology, this High Density PCB is optimized for applications where space is limited and component density is crucial. The use of RO4350B Glass Epoxy from Rogers Corp. ensures high performance with a Tg of 280℃ and Er<3.48, making it ideal for demanding environments.

The Copper Thickness options ranging from 0.5oz to 6oz provide flexibility for different design requirements, allowing you to customize the board based on your specific needs. Whether you need a thinner copper layer for more delicate applications or a thicker one for increased conductivity, this HDI PCB Board has you covered.

For surface finish, this High Density Model Board offers a variety of options including HASL, ENIG, OSP, Immersion Silver, and Immersion Tin among others. These finishes not only enhance the overall appearance of the board but also improve its durability and resistance to environmental factors.

When it comes to HDI PCB Manufacturing, precision is key. This product is manufactured with the highest standards to ensure consistency and reliability in every batch. The advanced manufacturing processes used in the production of this board result in a product that meets strict quality control measures and exceeds industry standards.

Whether you are working on a cutting-edge electronics project or a high-performance application, the HDI PCB Board is the perfect choice. Its high density interconnector technology, superior glass epoxy material, flexible copper thickness options, and variety of surface finishes make it a versatile solution for a wide range of electronic designs.

Features:

• Product Name: HDI PCB Board
• Surface Finish: HASL, ENIG, OSP, Immersion Silver, Immersion Tin, Etc.
• Finished Copper Thickness: 1oz
• Vias Aspect Ratio: 16:1
• Pcb Assembly Process: SMT THT DIP SMT PCB Assembly
• Min. Solder Mask Bridge: 0.075mm

Technical Parameters:

Applications:

High Density Interconnector (HDI) PCB boards are versatile and innovative products that find applications in a wide range of industries and scenarios due to their unique attributes such as surface finish options including HASL, ENIG, OSP, Immersion Silver, and Immersion Tin. The use of high-quality glass epoxy materials like RO4350B with a Tg of 280℃ and Er<3.48 from Rogers Corp ensures reliability and durability in various environments.

The key feature of HDI PCB boards is their ability to accommodate a high density of interconnections, making them ideal for advanced electronic devices that require intricate circuitry. With finished copper thickness options of 1oz and copper thickness ranging from 0.5oz to 6oz, these boards can meet the demanding requirements of modern electronics.

One of the key product application occasions for HDI PCB boards is in the development and manufacturing of HD SDI Converters. These devices rely on high density PCBs to support the complex signal processing and transmission requirements of high-definition video and audio signals.

Additionally, HDI PCB boards are widely used in communication equipment, aerospace technology, medical devices, automotive systems, and other industries where compact size, high performance, and reliability are essential. The superior surface finish options and copper thickness variations make HDI PCBs adaptable to diverse scenarios, from consumer electronics to industrial automation.

Whether it's designing a cutting-edge HD SDI Converter for broadcasting applications or creating sophisticated control systems for robotics, the high density and advanced features of HDI PCB boards make them a preferred choice for engineers and manufacturers looking to push the boundaries of technology.

Customization:

Product Customization Services for HDI Printed Circuit Boards:

VIP Process: Yes

Surface Mount Technology: Available

Surface Finish: HASL, ENIG, OSP, Immersion Silver, Immersion Tin, Etc.

Min. Solder Mask Bridge: 0.075mm

PCB Assembly Process: SMT THT DIP SMT PCB Assembly

Keywords: High Speed PCB Board, HDI PCB

Support and Services:

The HDI PCB Board product offers comprehensive Product Technical Support and Services to assist customers with any inquiries or issues they may encounter. Our team of experts is dedicated to providing prompt and efficient assistance, ensuring that customers receive the necessary support to maximize the performance and functionality of their HDI PCB Boards.
